In the case of CB, the 1/4 antenna at just under 10 feet long is the common "whip" that you may see on cars and trucks. That's obviously a little long to attach to your bumper, so people tend to use antennas that are a fraction of the wavelength: 1/2, 5/8, 1/4 and 1/8 are all common wavelengths for antennas.
#Cb antenna booster full
The CB portion of the spectrum begins at 25.01 megahertz, so a full wavelength antenna would be a bit more than 39.34 feet long. Tell us what other ideas you have in mind about CB antennas by commenting below.Wavelength (in feet) = 984 / frequency (in megahertz) You have to scrutinize what you need – from the type you prefer to where you’ll put it on your vehicle to maximize its efficiency. Getting a good CB radio antenna takes more than just purchasing one and slapping it on your 4×4. Take a look at the table below and see their corresponding price range. There are primarily 3 kinds of CB antennas. Prevents signal interference and rain and wind exposure.ĬB antennas vary in price hugely depending on the type or where they’re made from. Gives the CB antenna a permanent mounting position.Įasily adjusts or sways to the vehicle angle when ride is bumpy.
#Cb antenna booster install
Install aftermarket roof rack to factory mounts and put a metal sheet to roof rack and drill the center.Įasily switches the CB antenna from one vehicle to the next. Run a separate ground wire from the antenna ground side directly to the frame. Type of MountĬling on the roof gutter via a sturdy wire. If not, your CB antenna is as good as useless. However, in some cases, a ground plane is needed when mounting your CB antenna because it will serve as a conductor which will stabilize and amplify your CB antenna’s signal. There are 5 ways in which you can position your CB antennas based on your level of convenience. The place where you mount your CB antenna can make or break its signal reception due to the height and the prevalent kind of material surrounding it. HOW AND WHERE CAN YOU MOUNT YOUR CB ANTENNA? On the other hand, dual CB antennas’ transmission range pattern is a long oval which means it’s narrow and won’t be easily blocked, although the range on your left and right sides will be limited. Take note, its signal transmission pattern is circular which can easily be blocked by natural barriers. A single CB antenna will have a hard time giving the appropriate amount of signal due to the huge size of a camper that’ll be blocking its path. This is especially true if you’ll be pulling a camping trailer. Just make sure the dual CB antennas are situated around 8′ apart so they don’t overlap. Primarily, they boost the signal of your CB radios since there’ll be 2 of them working together. Yes, dual CB radio antennas under certain circumstances have more perks than a single CB radio antenna.
This explains why some areas have lower reception than others and that stronger power doesn’t always mean stronger signal as shown by the diagram above, where the right positioning of the CB antennas come into play. While the longer your CB antenna wavelength translates to a better reception, it’s also important to know that the scope or range of signal becomes slimmer and more concentrated on a particular place. Gain refers to the estimated level of power or signal that CB antennas emit as they gather radio frequencies from their surroundings and such amount of power is measured in decibel units. If you’re wondering which size of CB antenna is right for you, then using the wave formula should help you.
